Photoluminescent Pigment

Photoluminescent Pigment

Feedback    Download
Details

Introduction

The rare earth-activated alkali earth aluminate-Strontium(Sr) photoluminescent pigment, with the chemical formula of  MO·aAl 2O 3·bSiO 2·cL: Eu 2+Dy 3+, compounded by high-temperature solid phase reaction, is a novel, durable, effective, and environmentally friendly material.

Luminescent Mechanism: When exposed to certain wavelength of light, material was activated after the ground-state electron in the molecule absorbs energy, a transition is made to high energy track. However, as high-energy orbit is not stable, electronic spontaneously transit back to the original track while emitting energy in the form of light.

When there is light again, it stores energy again. So the photoluminescence process is circulatory.

  Characteristics:

1. Initial High Brightness:  in sunlight or under light radiation for 10 minutes, the intial brightness can reach more than 10000mcd/m 2

2. Long afterglow time: absorb light during the day, glow over 10 hours in the dark, its luminous intensity and the maintenance time is 30 times more than traditional luminescent material.

3. Safety and Environment Friendly:  non-toxic, harmless, non-inflammable, non-explosive, and radiation-free;

4. Weathering good: material stability and weathering resistance, excellent in outdoo r use with no limitation with unlimited glow cycles.

Application areas:

Suitable for various kinds of transparent medium, such as paint, screen printing, plastic, glass, coating, powder coating, ink, enamel, ceramic and fiber.

Indication position:

Can be applied in switch of home appliance, control board, plug, lock, electric torch, stairway, fire protection facility, fire alarm, lifesaving tools etc.

Safety areas:

Show safety indication effect in fields as below: Signs, warning items writing, emergency passenger path, subway station, underground passage, blindage project, hospital, dancing hall, video room, refuge shelter, helmet, bicycle etc.

Building: Can be practically and artistically applied to building wall, tiles, inside elevator, bridge, roads, sea ports etc.
Others:

Arts and crafts, amber, sand crystal, glass, painting works; toys: Plastic toys and piece together pictures; clothing: Shoes, caps, working uniform, helmet, transfer pictures, printing graph clothing; calendar, fishing tools.

Specification of Photoluminescent Pigment


Item

Type

Luminance after
10 min
  (mcd/ m²)

Luminance after
30 min
  (mcd/ m²)

Luminance after
60 min
  (mcd/ m²)

Median Size

(um)

 GJK Series

(Yellow-Green)

GJK200A

650±20

230±10

120±5

55-75

GJK200B

650±20

230±10

120±5

55-75

GJK300A

480±20

200±10

85±5

40-55

GJK350A

370±20

130±10

70±5

30-45

GJK400A

280±20

80±10

50±5

20-30

GHK

(Yellow-green)

GHK325H

420±20

180±10

80±5

30-40

GHK400A

450±20

190±10

85±5

20-30

 JK Series

(Yellow-Green)

JK-200A

530±20

200±10

90±5

55-75

JK-200B

530±20

200±10

90±5

55-75

JK-300A

400±20

160±10

70±5

40-55

JK-350A

300±20

100±10

50±5

30-45

JK-400A

220±20

50±10

27±5

20-30

JM Series

(Blue-Green)

JM-200A

450±20

200±10

100±5

65-80

JM-200B

450±20

200±10

100±5

65-80

JM-250A

350±20

140±10

66±5

35-65

JS Series

(Sky-Blue)

JS-200A

400±20

180±10

95±5

65-80

JS-250A

340±20

140±10

70±5

35-65


Package:

25kg /barrel (Volume: 33cm x 37.5cm), lined with two plastic bags,  and one dry placed in.

          Net Weight: 25kg/barrel      Gross Weight: 26kg/barrel

Storage:

Dry and sheltered
